●AC servo motor
The system, incorporating three AC servo motors and controlled by microcomputer, operates very quietly, and is excellent in productivity and controllability.
●Self-diagnostic function
If any failure should occur, operation is stopped automatically, and the trouble is warned by electronic buzzer and display, so that a quick counteraction can be taken.
●Open frame
The cleaning and the adjustment can be easily done because of the open frame structure.
●Belt exchange
Exchange of a belt became easy compared with the former.
The system, incorporating three AC servo motors and controlled by microcomputer, operates very quietly, and is excellent in productivity and controllability.
●Self-diagnostic function
If any failure should occur, operation is stopped automatically, and the trouble is warned by electronic buzzer and display, so that a quick counteraction can be taken.
●Open frame
The cleaning and the adjustment can be easily done because of the open frame structure.
●Belt exchange
Exchange of a belt became easy compared with the former.
| Capacity | 10〜120pack／min |
|---|---|
| Power Consumption | AC200V 3phases 5KVA 15A |
| Air supply | 500KPA 100NL/min |
| Machine size | L:3825mm W:1225mm H:1700mm |
| Product size | L:80〜300mm W:10〜180mm H:15〜60mm |
| Packing material | Heat fusible film(MAX 450mm) |
| Max. film width | 450mm≧（product height + product wideh）×2＋40mm |
※Specification varies with the shape, dimensions and properties of the merchandise to be packaged, packaging materials, and other conditions.
