●AC servo motor
The system, incorporating three AC servo motors and controlled by microcomputer, operates very quietly, and is excellent in productivity and controllability.
●Self-diagnostic function
If any failure should occur, operation is stopped automatically, and the trouble is warned by electronic buzzer and display, so that a quick counteraction can be taken.
●Open frame
The cleaning and the adjustment can be easily done because of the open frame structure.
The system, incorporating three AC servo motors and controlled by microcomputer, operates very quietly, and is excellent in productivity and controllability.
●Self-diagnostic function
If any failure should occur, operation is stopped automatically, and the trouble is warned by electronic buzzer and display, so that a quick counteraction can be taken.
●Open frame
The cleaning and the adjustment can be easily done because of the open frame structure.
| Capacity | 10〜60pack／min |
|---|---|
| Power Consumption | AC200V 3phases 7.0KVA 21A |
| Machine size | L:4480mm W:1090mm H:1700mm |
| Product size | L:100〜350mm W:80〜230mm H:5〜60mm |
| Packing material | Heat fusible film(MAX 500mm) |
| Max. film width | 500mm≧（product height + product wideh）×2＋50mm |
※Specification varies with the shape, dimensions and properties of the merchandise to be packaged, packaging materials, and other conditions.
