●AC servo motor
The system, incorporating four AC servo motors and controlled by microcomputer, operates very quietly, and is excellent in productivity and controllability.
●Self-diagnostic function
If any failure should occur, operation is stopped automatically, and the trouble is warned by electronic buzzer and display, so that a quick counteraction can be taken.
●Open frame
The cleaning and the adjustment can be easily done because of the open frame structure.
The system, incorporating four AC servo motors and controlled by microcomputer, operates very quietly, and is excellent in productivity and controllability.
●Self-diagnostic function
If any failure should occur, operation is stopped automatically, and the trouble is warned by electronic buzzer and display, so that a quick counteraction can be taken.
●Open frame
The cleaning and the adjustment can be easily done because of the open frame structure.
| Capacity | 30〜160pack／min |
|---|---|
| Power Consumption | Pacaging machine：AC200V 3phases 10KVA 30A Shrink tunnel：AC200V 3phases 4KVA 20A |
| Machine size | L:7610mm W:1210mm H:2090mm |
| Product size | L:80〜200mm W:80〜120mm H:20〜60mm |
| Packing material | Polywrap shrink film. OPP inner heat coating film (450mm Max,film width) |
| Max. film width | 450mm≧（product height + product wideh）×2＋50mm |
※Specification varies with the shape, dimensions and properties of the merchandise to be packaged, packaging materials, and other conditions.
