●AC servo motor
The system, incorporating three AC servo motors and controlled by microcomputer, operates very quietly, and is excellent in productivity and controllability.
●Self-diagnostic function
If any failure should occur, operation is stopped automatically, and the trouble is warned by electronic buzzer and display, so that a quick counteraction can be taken.
●Long seal（box motion type）
By the box motion type cut seal, sealed package and tight package can be made, and it is ideal for packaging by mixing with gas or deoxidizer.
The system, incorporating three AC servo motors and controlled by microcomputer, operates very quietly, and is excellent in productivity and controllability.
●Self-diagnostic function
If any failure should occur, operation is stopped automatically, and the trouble is warned by electronic buzzer and display, so that a quick counteraction can be taken.
●Long seal（box motion type）
By the box motion type cut seal, sealed package and tight package can be made, and it is ideal for packaging by mixing with gas or deoxidizer.
| Capacity | 10〜40pack／min |
|---|---|
| Power Consumption | Pacaging machine：AC200V 3phases 6.2KVA 18A Shrink tunnel：AC200V 3phases 9Kw 30A |
| Air supply | 500KPA 100NL/min |
| Machine size | L:5000mm W:998mm G:1900mm |
| Product size | L:75〜500mm W:80〜160mm H:25〜60mm |
| Packing material | Heat fusible film(MAX 460mm) |
| Max. film width | 460mm≧（product height + product wideh）×2＋40mm |
※Specification varies with the shape, dimensions and properties of the merchandise to be packaged, packaging materials, and other conditions.
